Cam Switches: Specifying Rotary Selector Switches for Metering and Control

A cam switch is usually the cheapest switching device on a panel and the one specified with the least care. It arrives as a line item reading something like "rotary switch, 25A, 3 position" — and then the panel shop discovers that the three positions are 60° apart instead of 90°, that the legend plate says OFF–1–2 while the contacts say 1–0–2, or that the ammeter selector breaks the current transformer circuit as it passes between phases.

None of those are manufacturing faults. They are specification faults, and they happen because a cam switch is not really described by a current rating and a position count. It is described by a contact sequence — which contact closes in which position — and that information lives in a diagram most purchase orders never reference.

This article covers what a cam switch actually is, the two quite different jobs it gets used for, how to specify one so the right device arrives, and the failures that come back to the panel shop.

---

What a cam switch is, mechanically

Strip the escutcheon off one and the construction is simple. A central shaft carries a stack of insulated decks (also called stages or modules). Each deck holds one or more contact pairs and a moulded cam that opens and closes those contacts as the shaft turns. Stack more decks on the shaft and you get more contacts, all driven in a fixed relationship to the handle position.

Everything that matters follows from that geometry:

• The cam profile, not the handle, decides the switching pattern. Two switches with identical handles, identical current ratings and identical position counts can have completely different contact behaviour because their cams are cut differently. The manufacturer encodes this as a switching diagram or contact sequence table.
• Positions are angular. A switch indexed every 90° gives you four positions per revolution; every 60° gives six; every 45° gives eight. The indexing angle and the number of usable positions are two separate parameters, and a switch can be built with mechanical end-stops that limit travel to fewer positions than its indexing would allow.
• Decks are modular, so the device is configurable to order. This is why cam switches come in enormous catalogue families rather than a handful of part numbers, and why a part number carries a long configuration string rather than a friendly description.
• The contact stack is enclosed and compact, which is also why thermal derating matters more than the headline rating suggests. More on that below.

GNTech supplies the Telergon cam switch range, series T, TB, TF and TP, spanning roughly 12 A to 1200 A across the family — from 22 mm panel-mount metering selectors at the small end up to base-mounted power switches sized for main-switch duty. The same mechanical principle covers that whole span; what changes with frame size is the deck construction and the operating mechanism, so read the series datasheet for what a given frame actually offers.

---

Two jobs, two completely different specifications

Almost every cam switch on an industrial board is doing one of two things, and conflating them is the root of most ordering errors.

Job one: selecting a measurement

Metering selectors switch instrument circuits, not load current. An ammeter selector switch moves one ammeter between three phase current-transformer secondaries. A voltmeter selector switch moves one voltmeter between phase-to-phase and phase-to-neutral combinations. The current through the contacts is small; the consequences of the wrong contact sequence are not.

GNTech stocks both as 22 mm panel-mount units — a 25 A ammeter cam switch and a 25 A three-phase voltmeter cam switch — where that 25 A is the contact's thermal capability, not the current you are measuring. The CT secondary loop carries 1 A or 5 A nominal; the switch is rated well above it so that CT fault current and the short-time duty of the shorting contacts are comfortably within the contact rating.

Job two: switching power or control

Here the cam switch is in the circuit, making and breaking real load current: a local on–off switch, a manual source changeover, a star–delta starter sequence, a motor reversing switch, a multi-speed selector, or a hand–off–auto selector in a control circuit. GNTech's catalogue includes a cam-type changeover switch with a centre OFF position, 1–0–2, three-pole, which is the classic manual source-selection arrangement.

The specification questions for job two are about current, utilisation category, derating and breaking capacity. The specification questions for job one are almost entirely about contact sequence. Treat them as different procurement problems.

---

The contact sequence is the specification

If you take one thing from this article: order a cam switch against its switching diagram, not against a prose description.

A switching diagram is a grid. Columns are handle positions; rows are the contact pairs across all decks; a mark in a cell means that contact is closed in that position. Everything ambiguous about the device becomes unambiguous in that grid:

• Which contacts are closed in the "off" or centre position — if any.
• Whether the switch breaks before it makes (the normal case: the outgoing contact opens before the incoming one closes, so two sources are never paralleled) or makes before it breaks (needed for CT circuits, as below).
• Whether an auxiliary contact changes state early or late relative to the main contacts — which is what lets a cam switch signal its own position to a PLC or an indicator lamp.
• Whether the sequence is maintained (stays where you leave it) or spring-return (snaps back to a home position when released) — and from which positions.
• Whether travel is continuous through all positions or blocked by an end-stop.

Prose cannot carry that. "Three-position changeover with centre off" describes at least half a dozen genuinely different devices once you include auxiliary contacts and sequence timing. The diagram number — which appears on the datasheet alongside the part number — is the thing to put on the order, and the thing to check on arrival before the board is wired.

---

The ammeter selector trap: never open-circuit a CT

This is the single most important technical point about cam switches, and it is routinely missed.

A current transformer in service is a current source. Its secondary is designed to work into a near short-circuit — the ammeter coil, the relay burden, the wiring. If you open that secondary while primary current is flowing, the CT has no burden to drive and the core drives towards saturation, developing a dangerously high voltage across the open terminals. That voltage is a shock hazard at the terminal block and an insulation hazard inside the CT itself. This is why CT secondaries are earthed at one point and why a CT not in use is fitted with a shorting link.

An ammeter selector switch is a device whose entire job is to move a meter between three CT secondaries — which means it spends part of every operation in transition between phases. A correctly specified ammeter selector therefore has a make-before-break contact sequence, with shorting contacts arranged so that:

• the two unselected CT secondaries are shorted out through the switch at all times, and
• the selected CT's short is removed only once the meter is already in circuit, and re-applied before the meter leaves it.

A generic "three-position rotary switch" does not do this. A break-before-make switch of the right current rating, the right position count and the right indexing angle will fit the panel cut-out perfectly, carry the legend ammeter selector, and open-circuit a live CT every time an operator turns it. It will also appear to work, because the meter reads correctly in each of the three settled positions. The hazard only exists during the fraction of a second of transition, so it does not show up in commissioning checks — which is exactly why this must be caught at specification.

Order the device as an ammeter selector switch with its diagram, not as a rotary switch with three positions. If a board arrives with a selector whose provenance you cannot establish, verify the shorting behaviour before energising the CT circuit, and treat an unidentified selector in a CT circuit the same way you would treat an unlabelled isolation point during fault finding on industrial switchgear.

Voltmeter selectors have no equivalent hazard — a voltage circuit is happy open — but they do need the opposite discipline: the instrument circuit must be fused or otherwise protected close to its origin, because the switch is now connecting a meter across two phases through a long run of small-section wiring.

---

Ratings, utilisation categories and the derating nobody applies

For a cam switch doing load-switching duty, three numbers describe it and they are not interchangeable.

Conventional free-air thermal current (Ith) is the current the contacts can carry continuously in open air at a defined ambient, usually 40 °C, without exceeding their temperature-rise limits. This is the number marketing material tends to use, and it is measured under conditions your panel does not reproduce.

Rated operational current (Ie) is the current the device can make and break at a stated voltage in a stated utilisation category. It is always the number to design against, and it is lower than Ith for inductive duty.

Utilisation category tells you what kind of load the device was tested against. Under IEC 60947-3, the AC categories run roughly:

The A and B suffixes distinguish frequent from infrequent operation. For control-circuit duty — a cam switch commanding a contactor coil rather than a load — the relevant standard is IEC 60947-5-1, with its own categories for switching electromagnetic loads, and the figure of merit becomes the contact's ability to break coil inductance reliably at low current rather than its thermal rating.

Then apply the derating that actually bites:

• Ambient temperature. A board in an unventilated plant room in Gauteng in February is not at 40 °C internally. Above the reference ambient, the permitted continuous current falls.
• Deck count. Each loaded deck dissipates heat into the same enclosed stack. A switch configured with many current-carrying decks derates below the same frame carrying one.
• Enclosure and grouping. The device is inside an assembly which is itself subject to temperature-rise verification under IEC 61439. The assembly's rated diversity factor and verified temperature rise are the governing numbers for the complete board, not the component datasheet.
• Duty cycle. Frequent operation under AC-23 duty wears contacts; electrical endurance in operating cycles is a datasheet figure and a maintenance-planning input, which is where it meets your switchgear maintenance programme.

The failure mode when derating is skipped is contact welding or erosion rather than a dramatic fault: the switch gets hot, the contact resistance rises, the heat rises further, and eventually the handle turns without the circuit changing state — or the contacts refuse to part. Our switchgear sizing and load calculation guide covers the broader version of this calculation for the devices upstream.

---

Mounting, the operator interface and ingress protection

A cam switch is one of the few devices on a board that a non-electrician touches, so the mechanical interface is part of the specification.

Panel-mount (22 mm). The small metering selectors mount through a standard 22 mm cut-out in the same way as a pilot light or pushbutton, with the contact stack hanging behind the front plate inside the enclosure. 22 mm is the standard aperture for panel-mounted pilot devices, so it is the same cut-out used for indicator lamps and pushbuttons.

Base or plate mount with door-operated handle. Larger switches bolt to the gear plate and are driven through the door by an extension shaft and an external handle with an escutcheon. Three dimensions have to agree here: the shaft length must match the distance from the mounted device to the inside of the door, the escutcheon must seal the door aperture to the enclosure's IP rating, and the handle's indexing must align with the printed legend so that the marked position is the actual position. Getting the shaft length wrong is one of the most common panel-shop reworks, because it is determined by the enclosure depth and the mounting plate offset rather than by the switch itself.

Ingress protection is a property of the installed assembly, not of the switch. A device with an IP-rated front plate maintains that rating only when it is mounted in a correctly cut aperture with its sealing gasket fitted. Pick the operator's rating from the environment — washdown areas, dusty plant, outdoor kiosks — and check it against the enclosure rating, as covered in our switchgear installation best practices.

Legending and position marking. The legend plate must match the contact sequence, in the site's operating language, with the positions marked in the order the cam actually indexes them. Mismatched legends are a live safety issue: an operator who believes the switch is in position 2 when the contacts say 1 will make the wrong decision under pressure.

Lockability. Some cam switch handles accept a padlock in the off position. Whether a given handle does — and whether that lock holds the mechanism rather than just the door — is a datasheet question, and the distinction matters enormously if the device is being treated as a point of isolation. See our guide to lockout/tagout and locking devices for why that is a specification question rather than a procedural one.

---

Where a cam switch is the wrong device

Three substitutions come up repeatedly, and all three are worth refusing.

It is not an isolator unless it is declared suitable for isolation. Suitability for isolation is a specific declaration under the switchgear standards: a guaranteed isolating distance across the open contacts, defined leakage current, impulse withstand, and positive indication that the handle cannot show OFF unless the contacts are genuinely open. Whether a particular cam switch carries that declaration is a line on its datasheet, and it is not safe to infer from the frame size or the current rating. If your isolation register lists a device, check that the device's own documentation makes the declaration — the device-class distinctions are set out in our comparison of switch disconnectors, circuit breakers and isolators.

It is not a protective device. A cam switch has no overcurrent sensing and no interrupting rating for fault current. Short-circuit protection stays with the fuse or circuit breaker, and the switch's short-circuit withstand (its conditional rating in combination with a specified upstream protective device) is what you verify — not a breaking capacity it does not have.

It is not automatic transfer. A manual changeover cam switch with a centre OFF is an excellent, highly reliable way to select between two sources when somebody is there to turn it. It does not detect supply failure, it does not enforce a transfer delay, and it cannot synchronise anything. Where the application needs unattended transfer, the device class is different and the control is different — see manual versus automatic changeover switches. This is a routine decision point on South African sites running generator or battery backup, and it is worth making deliberately rather than by default: the same question appears in our coverage of load-shedding resilience and solar power distribution for industrial sites.

---

A specification checklist

Put these on the enquiry and the device that arrives will be the device you wanted.

1. Function in plain words — ammeter selector, voltmeter selector, on–off, 1–0–2 changeover, star–delta, reversing, hand–off–auto.
2. Switching diagram reference from the manufacturer's catalogue, or a drawn contact sequence grid if nothing standard fits.
3. Positions and indexing angle, plus whether travel is limited by end-stops and whether any position is spring-return.
4. Contact sequence requirement: break-before-make, or make-before-break where a CT circuit or an uninterrupted control path demands it.
5. Poles and current-carrying decks, separately from auxiliary contacts.
6. Rated operational current and voltage at the correct utilisation category, with the derating for ambient and deck count applied — not the free-air thermal current.
7. Auxiliary contacts: how many, normally open or closed, and at which point in the travel they change state.
8. Mounting arrangement: 22 mm panel, base, or door-operated with the measured shaft length and the escutcheon type.
9. IP rating required at the operator, and confirmation it is compatible with the enclosure.
10. Legend plate text and language, matched to the sequence.
11. Lock-off provision, if the device appears anywhere in an isolation procedure.
12. Short-circuit withstand in combination with the specified upstream protective device.

---

The failures worth designing out

Collecting the themes above into the things that actually come back:

• An ammeter selector that breaks the CT circuit. Specified as a generic rotary switch. Invisible at commissioning. Fix at specification, by diagram.
• Contact welding from an under-derated switch. The rating was free-air; the installation was an enclosed board with multiple loaded decks in a hot room.
• A star–delta or reversing sequence with the wrong cam. Wired to the diagram the designer assumed rather than the diagram the device shipped with. Check the device against its own datasheet before wiring.
• The wrong shaft length. Determined by enclosure depth, not by the switch. Measure, do not assume.
• A legend that disagrees with the contacts. Cheap to prevent, expensive when an operator acts on it.
• A selector carried in the isolation register without a suitability-for-isolation declaration. The procedure then documents a control that does not exist.

Every one of these is caught by the same discipline: specify the contact sequence, derate the rating for the real installation, and verify the device against its datasheet before it is wired rather than after it is energised. The equipment is inexpensive. The rework, and the hazard in the CT case, are not.
